8×4 U-shape 23cbm Dump Truck

HOWO 8x4 U-shape 23cbm Dump Truck for Algeria

The HOWO 8×4 U-Shape 23cbm Dump Truck is a robust and efficient heavy-duty vehicle designed for construction, mining, and bulk material transportation in demanding environments like Algeria. With its U-shaped high-strength steel cargo body, powerful engine, and reliable chassis, this dump truck ensures high load capacity, durability, and operational efficiency.

Key Features:

✔ 8×4 Drive Configuration – Enhanced traction and stability for off-road and rugged terrain.

✔ U-Shaped Cargo Body (23 Cubic Meters) – High-strength steel construction prevents material adhesion and improves unloading efficiency.

✔ Heavy-Duty Chassis – Reinforced frame and suspension for long-lasting durability under heavy loads.

✔ Comfortable & Safe Cabin – Ergonomic design, air suspension seat, and enhanced visibility for driver safety.

HOWO 8x4 U-shape 23cbm Dump Truck for Algeria

Specification

Basic Information	Drive type	8x4
	Driving mode	Left Hand Driving
	Horsepower	400hp
Dimension	Length Estimated(mm)	10200
	Width Estimated (mm)	2500
	Height Estimated (mm)	3800
	Frame(mm)	Double deck frame (8+8/300)
	Wheelbase Estimated(mm)	1800+3225+1400
Upper body	Dump body size (mm)	6800X2300X1500
	Bucket capacity (cubic meters)	23.46cbm
	Thickness of body steel (mm)	Floor 8 mm; side 6 mm
	Shape	U type
	Tipping system	Front tipping system
Engine	Brand	WEICHAI
	Model	WP12.400E201
	Emission standard	Euro Ⅱ
Axles	Front axle(kg)	VGD95 front axle (drum brake)
Axles	Rear axle(kg)	MCP16ZG double rear axle(drum brake), speed rate5.26
Transmission	HW19709XST transmission +direct coupling HW50 PTO
Steering	Bosch
Suspension	Front and rear enhanced multi springs
Tyre	12.00R20 （12+1) Pieces
Bumper	High bumper (all metal)
ABS	ABS(4S/4M)
Fuel Tank	400L Aluminium alloy
Cab	HW76
