Main Technology Parameter
Model name FAW J6P dump truck
Model CA3250P66K2T1E5
Driving type Left hand drive
Traction type 6×4
Color optional
Weights
Gross Vehicle Weight(kg) Approx.12300
Dimensions
Wheelbase(mm) 4050+1350
Overall dimension(mm) Approx. 8800х2550х3680
Engine
Engine model  Xi chai CA6DL2-37E5 (BOSCH common rail+SCR)

 370HP
Emission standard Euro 5
Engine type 4 stroke water-cooled, inter-cooling
No. of cylinders straight-6 cylinders
Displacement(L) 8.6 / Diesel
Max. output (kw) 279
Fuel Tanker（L） 400L aluminum fuel tank
Drive   Line
Gearbox FAST 12JSD160T transmission

(spline output power   take-off)
12 forwards, 2 reverse gear, manual gearbox
Maximum input torque 1600N.m
Steering Power steering
Brake Air brake, engine exhaust brake
Clutch 430 diaphragm
Cab
Cabin J6P fully floating flat top row half cab, LCD   instrument panel, electric window regulator, manual rearview mirror, and   dedicated seats
Standard configuration Automatic air conditioning, two point spiral   spring suspension at the back of the cab, electric hydraulic lifting device,   "engine running time" function can be viewed through the instrument   panel, and reflective signs in the cab
Axle
Front axle 2020 front axle
Rear axle Axle ф 300 cast wheel reduction axle (automatic   adjustment arm, imported ABS, 8-hole V-rod)

double reduction pneumatic brake, double   reduction driving axles with inter-wheel & inter-axle differential locks
axle ratio 5.263
Tire   specification
Tire specification 12.00R20

standard tire,10 tires+1   spare part
Parameter
Economic speed/maximum speed(km/h) 40～55/75
Max. Gradeability 45(%)
Rear overhang(mm) 1000
Suspension Leaf spring, 13/14
Frame(mm) 300×80×(8+8+5)
Color Customized
Other Front lower protection device,   iron bumper, desert air filter, suspension with front/rear multiple, raised   hydraulic support, rear suspension with 1000mm, 180Ah battery, TRW steering   gear, long-term fuel prefilter module, vehicle speed limit of 89km/h, adjustment   of ABS solenoid valve bracket installation direction (flipped 180 ° on the   existing foundation), reserved compartment floor heating interface on the   muffler, with interface plug cover, and reserved emergency call system   interface
Body parameters
Body dimension(mm) 5800x2300x1500
Body volume(m3) 20
Material Carbon steel plates
Lifting method Front hydraulic lifting system
