Main Technology Parameter
Model name FAW   J6P dump   truck
Model CA3250P66K24L2T1E
Driving type Left hand drive
Traction type 6×4
Color optional
Weights
Gross Vehicle Weight(kg) Approx.12300
Dimensions
Wheelbase(mm) 3800+1350
Overall dimension(mm) Approx. 8850×2495×3450
Engine
Engine model CA6DM2-39E3F(EGR)

 390HP
Emission standard Euro 2
Engine type 4 stroke water-cooled,   inter-cooling
No. of cylinders straight-6 cylinders
Displacement(L) 11.04 / Diesel
Max. output (kw) 290
Fuel Tanker（L） 400 steel fuel tank
Drive   Line
Gearbox CA10TAX190M flange power take-off
10 speeds, 10 forwards, 2   reverse gear, manual geabox
Maximum input torque 1900N.m
Steering Power steering
Brake Air brake, engine exhaust   brake
Clutch 430 diaphragm
Cab
Cabin New J6P African version   fully floating flat top row half cab,

Mechanical damping seat,

Can be tipped forwardly,   with inner A/C and one sleeper bed
Standard configuration Two point spiral spring   suspension at the rear of the cab

Metal bumper
Axle
Front axle 2020 front axle
Rear axle Cast iron improved wheel   reduction axle

double reduction pneumatic   brake, double reduction driving axles with inter-wheel & inter-axle   differential locks
axle ratio 5.921
Tire   specification
Tire specification 12.00R20

standard tire,10 tires+1   spare part
Parameter
Economic speed/maximum speed(km/h) 40～55/75
Max. Gradeability 35(%)
Rear overhang(mm) 1000
Suspension Leaf spring, 12/12
Frame(mm) 300×80×(8+8)
Color Customized
Body parameters
Body dimension(mm) 5600x2300x1500
Body volume(m3) 20
Material Carbon steel plates
Lifting method Front hydraulic lifting   system
