Basic Info.

Item Value
Product Range Foton Mars V9
Drive Type 4x4
External Dimensions (LxWxH) mm 5541x2030x1905
Cargo Compartment Dimensions (LxWxH) mm 1560x1650x530
Wheelbase 3355 mm
Gross Vehicle Weight 3000 kg
Curb Weight 2200 kg
Rated Load Mass / Number of Passengers 500 kg / 5
Engine Model 4F20TC + 48V
Emission Standard Euro V / Euro VI
Displacement 2.0L
Power 120 kW / 160 hp
Max Torque 450 N.m / 1800-2600 rpm
Transmission ZF 8HP50
Rear Axle 2.2T / 3.91
Suspension Front: Double wishbone independent suspension, Rear: Multi link integral axle suspension
Tires 265/70R18
Minimum Ground Clearance 240 mm
Maximum Speed 160 km/h
Maximum Gradability 30% (2WD) / 60% (4WD)
Origin China
Packaging OEM Carton or Custom Crate
MOQ 10 pcs
Lead Time 3–7 days (express) / 35–60 days (bulk sea)
Warranty 3 years or 100,000 kilometers

Detailed Specifications

Engine

  • Model: 4F20TC + 48V
  • Emission Standard: Euro V / Euro VI
  • Displacement: 2.0L
  • Power: 120 kW / 160 hp
  • Max Torque: 450 N.m / 1800-2600 rpm

Dimensions and Capacity

  • External Dimensions (LxWxH): 5541 mm x 2030 mm x 1905 mm
  • Cargo Compartment Dimensions (LxWxH): 1560 mm x 1650 mm x 530 mm
  • Wheelbase: 3355 mm
  • Gross Vehicle Weight: 3000 kg
  • Curb Weight: 2200 kg
  • Rated Load Mass / Number of Passengers: 500 kg / 5

Safety and Comfort

  • Rear Axle: 2.2T / 3.91
  • Suspension: Front: Double wishbone independent suspension, Rear: Multi link integral axle suspension
  • Tires: 265/70R18
  • Minimum Ground Clearance: 240 mm
  • Maximum Speed: 160 km/h
  • Maximum Gradability: 30% (2WD) / 60% (4WD)
  • Other Configurations:
    • Luxury car interior and technology configuration
    • Driver seat 12-way electric adjustment with front seat heating and ventilation
    • Automatic constant temperature air-conditioning
    • 14.6-inch intelligent central control large screen with Carplay and Carbit system
    • AI intelligent voice interaction system
    • Dual airbags + side airbags + side air curtains + pre-tightened seat belts
    • L2.5 intelligent driving system

After Sales

  • Warranty: 3 years or 100,000 kilometers

Key Features

  • 4x4 Drive Type: Suitable for various road conditions.
  • Ultra-wide Body: 2030 mm wide body for increased stability and comfort.
  • Luxury Interior: Sedan-like interior with advanced technology features.
  • Powerful Engine: 4F20TC + 48V hybrid system with 120 kW power and 450 N.m torque.
  • ZF 8AT Gearbox: Ensures smooth and efficient transmission.
  • Advanced Safety Features: Dual airbags, side airbags, side air curtains, and pre-tightened seat belts.
  • Comfort and Convenience: Electric seat adjustment, heating, ventilation, and intelligent central control screen.
